| Model | Unit | NS45 |
| Rated Load | kg | 700 |
| Tipping Load | kg | 1400 |
| Bucket Capacity | m³ | 0.4 |
| Operating Weight | kg | 2850 |
| Max. Travel Speed | km/h | 12 |
| Hydraulic Pump Flow | L/min | 75 |
| Fuel Tank Capacity | L | 70 |
| Tire Type | 10-16.5NHS | |
| Dimensions | mm | 3490×1730×2150 |
| Max.Operating Height | mm | 3980 |
| Hinge Pin Height | mm | 3080 |
| Bucket Width | mm | 1740 |
| Track Width | mm | 1450 |
| Wheelbase | mm | 991 |
| Ground Clearance | mm | 185 |
| Dumping Angle | 40 | |
| Dumping Height | mm | 2380 |
| Dumping Reach | mm | 750 |
| Engine Maker/Model | XinChai C490BPG | |
| Power/Rotate Speed | kw/rpm | 36.8(50HP)/2650 |
| Type | Water-cooled, 4-stroke | |
| Displacement | L | 2.27 |
| Standard Configuration | Enclosed cab | |
| Mechanical type | ||
| Options | Yanmar engine | |
| Starting assist system | ||
| Pilot control | ||
| Air conditioning |
Product Description
This skid wheel loader is equipped with a high-performance 50-horsepower engine, providing stable output and powerful performance, and can easily handle various complex working conditions. Whether it is site transportation, garden construction, or road maintenance, it can demonstrate outstanding operational efficiency.
It adopts a compact body design and a four-wheel drive system, with a small turning radius and flexible operation, making it highly suitable for work in narrow spaces. The unique sliding steering system enables in-place rotation, significantly enhancing construction efficiency.
In addition, this skid steer loader is equipped with a sensitive hydraulic control system and a user-friendly control handle. The operator can precisely control every movement to achieve rapid loading and smooth unloading, making the operation more effortless, smooth, and safe. Whether in terms of reliability, comfort or service life, this skid loader demonstrates the quality and durability expected of professional construction equipment.
