388T挖掘装载机技术参数 The Technical Parameter of 388T Backhoe Loader
| |
|
整机操作重量 Overall Operating Weight |
8000KG |
运输尺寸Transport Dimension | |
长×宽×高mm L*W*H |
6900×2260×2850mm |
轴距Wheel base |
2320mm |
|
最小离地间隙 Min. Ground Clearance |
300mm |
装载斗容Bucket Capacity |
1.5m3 |
掘起力Breakout Force |
38KN |
|
装载举升能力 Loading Lifting Capacity |
2800KG |
|
铲斗卸载高度 Bucket Dumping Height |
2900mm |
|
铲斗卸载距离 Bucket Dumping Distance |
1062mm |
反铲斗容Backhoe Capacity |
0.3m3 |
|
最大挖掘深度 Max. Digging Depth |
4100mm |
|
可选挖深 Optional Digging Depth |
5000mm （挖臂带伸缩） |
|
挖斗回转角 Swing Angle of backhoe |
190o |
|
最大牵引力 Max. Pulling Force |
39KN |
发动机Engine | |
品牌/型号Brand/Model |
YUCHAI YCD4J22T-115 Turbo engine涡轮增压发动机 |
型式Type |
单列、直喷、四冲程、水冷 In Line，Direct injection，Four-Stroke，Water Cooling |
额定功率Rated Power |
85KW |
可选发动机Optional Engine |
YUCHAI/YCD4T33T6-115(国三90KW） CUMMINS 74KW 4BT3.9-C100 CUMMINS EURO3 75KW QSB3.9-C100 EURO5 YUCHAI or EPA4 CUMMINS engine |
转向系统Steering System | |
转向角Steering Angle |
±36 o |
|
最小转弯半径 Min. turning radius |
6581mm |
|
系统压力 Pressure of the system |
12Mpa |
驱动桥Axle | |
品牌Brand |
前轮云宇转向驱动桥FEICHENG YUNYU |
|
主传动类型 Main Transmission Type |
双减速 Double Reduction |
轮边减速型式Final Reducer |
一级轮边减速Single Stage Final Reducer |
|
额定载重 Rated Loader of Axle |
4/18.5t |
传动系统Transmission System | |
变矩器Torque Converter | |
型号Model |
YJ280 |
型式Type |
单级、单相三元件Single-stage Three Elements |
冷却方式Cooling Method |
油冷压力循环Oil-cooling Pressure Circulation |
变速箱Gearbox | |
型式Type |
定轴式动力换档Fixed Shaft Power Transmission |
档位数Gears |
前进2档，后退2档Two Gears Ahead, Two Gears Astern |
最高车速Max.Speed |
30Km/h |
轮胎Tyre | |
规格Model |
（F）14-17.5前轮 （R）19.5L-24后轮 |
|
前轮气压 Pressure of Front wheel |
0.22 Mpa |
|
后轮气压 Pressure of Back Wheel |
0.22 Mpa |
制动系统Brake System | |
行车制动Service Brake |
气顶油钳盘制动Air Over Oil Caliper Brake |
|
外置式External Type |
|
自调节Self-regulation |
|
自平衡Self-balance |
|
驻车/紧急制动 Emergency Brake |
操纵力实施制动Operation Power Implementing brake |
|
手操纵力解除制动Manual Operation Power Terminating Brake |
液压系统Hydraulic System | |
|
液压系统压力 Pressure of Hydraulic System |
22Mpa |
|
挖斗挖掘力 Digging Power of Excavator Grab |
46.5KN |
|
铲斗掘起力 Digging Power of Dipper |
31KN |
|
铲斗提升时间 Bucket Lifting Time |
5.4S |
|
铲斗下降时间 Bucket Lowering Time |
3.1S |
|
铲斗卸料时间 Bucket Discharge Time |
2.0S |
|
装箱量 Packing Quantity（1*40HC） |
2Units(拆轮胎/挖臂/铲斗，用工艺轮装箱) |
标配Standard：前铲带铲斗，后挖带挖斗，豪华带内饰驾驶室/风扇/LED灯/大倒影/破窗锤/灭火器/推拉窗/天窗，暖风，豪华可调式旋转座椅，可调式仪表盘，液晶显示屏，液压先导操作，玉柴85KW发动机，14-17.5真空前轮胎，19.5L-24真空后轮胎，特制280整体变速箱，前轮云宇转向驱动桥，四轮驱动，A形支腿。 | |
|
注：以上参数或者配置如有变更，怒不另行通知。 The parameters or configuration are subject to change without notice. | |
