| tipe Model | Unit | NS45 |
| beban terukurRated load | kg | 700 |
| beban balikTipping load | kg | 1400 |
| kapasitas bucketBucket capacity | m³ | 0.4 |
| berat pengoperasianOperating Weight | kg | 2850 |
| kecepatan maksimal | km/jam | 12 |
| aliran pompa hidrolik | L/menit | 75 |
| kapasitas tangki bahan bakar | L | 70 |
| jenis Ban Tire type | 10-16.5NHS | |
| dimensi keseluruhan | mm | 3490×1730×2150 |
| tinggi Operasi Maksimum | mm | 3980 |
| tinggi Pin Sambungan | mm | 3080 |
| lebar dengan Bucket | mm | 1740 |
| jarak Roda Track width | mm | 1450 |
| jarak Sumbu Roda Wheelbase | mm | 991 |
| jarak ke Tanah | mm | 185 |
| sudut Pembuangan | 40 | |
| tinggi pembongkaran Dumping height | mm | 2380 |
| jarak pembongkaran Dumping reach | mm | 750 |
| merek/Model mesin Engine Maker/Model | XinChai C490BPG | |
| daya/kecepatan putar Power/Rotate speed | kW/menit | 36,8(50HP)/2650 |
| jenis Type | empat langkah berpendingin air Water cooled,4 stroke |
|
| perpindahan | L | 2.27 |
| konfigurasi standar | kabin tertutup | |
| kontrol manual | ||
| konfigurasi opsional | mesin YanmarYanmarengine | |
| sistem bantu start suhu rendah | ||
| kontrol pilot | ||
| pendingin Ruangan |
